Solar powered GNSS tracking device, 4G LTE, GSM; GPS+BDS+LBS+Wi-Fi, IP68.
LTE 4G solar-powered GNSS tracker designed for the management of construction vehicles and vessels. Featuring the solar panel, magnetic charger, and IP68 waterproof rating, this device is ideal for a variety of deployments that require long standby time and continued optimal performance. LTE communication with GSM (2G) fallback ensures a solid connection in almost all cases. In addition to these features, multiple working modes, various peripheral accessories and the suite of event-triggered alerts will make the tracker a valuable part of your fleet management strategy.
Tracker requires SIM card with data. SIM card must be purchased separetly from your provider
Features:
GPS + BDS +LBS multiple positioning ensures that the device's position is accurately displayed on the cloud platform.
LTE 4G connectivity with GSM 2G fallback.
Tamper alert: When the pressure-sensitive button is loose, you'll get notified of device removal.
Vibrating alert, warning on unusual temperature/humidity or low battery.
Long battery life and fast charging: industrial-grade lithium polymer 10000 mAh rechargeable battery, supports magnetic charging 5V/2A (only USB cable included).
IP67 water and dust resistance, robust and reliable design ensures stable operation in tough conditions.
BT configuration supported, BLE5.0 protocol.
GSM card is not included.
Specifications:
Positioning system: GPS+BDS+LBS+Wi-Fi+AGPS.
Tracking sensitivity: -165dBm.
Acquisition sensitivity: -148dBm.
Positioning accuracy: <2.5m CEP.
GNSS accuracy: <10 meters.
Cellular network: LTE Cat1/ LTE Cat M1/ Cat NB2/ GSM.
Network frequency: GSM: B2/B3/B5/B8; LTE FDD: B1/B3/B5/B7/B20/28; LTE TDD: B38/B40/B41.
Time to First Coordinate (TTFF):
Coordinate time of receipt when the time and the last coordinate of the location are known (hot start) <1 sec.
Coordinate acquisition time when initial coordinate and time are not known (cold start) <32 sec.
Other specifications:
Battery: 10000mAh/3.7V industrial grade Li-polymer battery.
Operating current: 120mA.
Charging voltage: 5V/2A (charger should be purchased separately, only USB cable included).
Solar power: 5V/390mA @STC (STC: 38000lux halogen lamp direct illumination on test).
Standby time: up to 2 years in battery saving mode.
Working modes: GPS mode / tracking mode / power saving mode.
Supported SIM card: nano-SIM.
LED indicator: red (GMS signal) / green (battery level).
Operating temperature: -25°C~+70°C.
Operating humidity: 5%~95% (non-condensing).
Sensor: accelerometer, temperature and humidity sensor, Hall effect sensor.
Size: 200x90x25mm.
Weight: 480g (with base 548g).
Safety class: IP68.
Fixing: 3M on the base with screws.
Set includes:
Tracking device.
Base.
USB charging cable (magnetic to USB Type-A).
Set of screws.
Coordinated and tested with Tracksolid.com on Windows, Android, iOS.
The app allows you to configure your device and track all the information you collect - location, time, status, and more.
Warranty: 24 months.
