Description
Technical data
| Brand | Yato |
| Entity responsible for this product in the EU | |
| Series | GRD |
| Diameter | 1, 2, 3, 4, 5, 6, 7, 8, 9, 10 mm |
| Overall length | 34, 49, 61, 75, 86, 93, 109, 117, 125, 133 mm |
| Working part length | 12, 24, 33, 43, 52, 57, 69, 75, 81, 87 mm |
| Holder size | 1/4" (6.3 mm) |
| Toolholder type | hexagonal |
| Rotations | 3800, 4000, 2600, 2000, 1600, 1300, 1100, 1000, 900, 800 min⁻¹ |
| Material | HSS 6524 |
| Surface finish | coated with titanium nitride, refined |
| DIN | 338 |
| Drill bit point angle | 135 ˚ |
| Split point | yes |
| Pcs | 10 |
| Application | stainless steel, acid-resistant steel, cold rolled steel |
| Symbol | YT-44674 |
