Inverter welding semi-automatic 2in1 MIG+MMA 250A, 220V IGBT (GET001) - is a multifunctional welding machine made based on the most advanced inverter technologies. Thanks to the use of inverter technology, the power consumed by the machine, as well as its dimensions, become smaller, and efficiency increases by more than 30%.
This welding machine is designed for both wire welding in a protective gas environment and self-shielded wire (flux, without gas). When the welding torch is connected to the positive terminal and the grounding to the negative, the current increases during the welding process, which is used for MIG/MAG welding in a protective gas environment. Reverse polarity is used when welding with self-shielded wire, where high heat is not required during the welding process.
Main welding methods available on this equipment:
- mechanized welding in protective gas and mixtures (MIG and MAG);
- mechanized welding with self-shielded flux-cored wire (FCAW).
Using these methods, the machines can perform welding and surfacing of all types of steels, aluminum, its alloys, and other metals from 1 mm, both in direct and reverse polarity. The cross-section of the wire used is 0.6 and 1.0 mm. The maximum weight of the wire spool that can be installed on the machines is 5 kg.
An additional welding method is manual arc welding with a coated electrode (MMA) for metals and alloys with a thickness of 2.5 mm and above.
The machines have additional features that make the welding process more convenient and comfortable: wire burn-back adjustment, wire idle run button.
The machine has the most modern working characteristics and ensures welding quality thanks to the use of the latest IGBT technology.
The main characteristics of this inverter machine are:
- The machine uses an arc between the wire and the material being welded as a heat source for melting the wire and processing the metal, and then supplies protective gas to the welding zone, which forms the weld pool.
- Compact size and lightweight, making the machine widely used for upholstery, repair work, and in field conditions.
- Excellent arc ignition and metal transfer.
- Various protective measures prevent the machine from overheating, overvoltage, voltage drop, excessive current, etc.
- High performance. Thanks to automatic wire feeding, welding can be performed in a fast speed mode.
- There are no special requirements for the welding wire used. Both solid and flux wires are suitable. Wire diameter ranges from 0.6 to 1.0 mm.
- Convenient connection. External connectors make connections safe, quick, and reliable.
- MMA welding function. Performed with rutile or cellulose electrodes.
- All current data values are displayed on the machine's digital display. This allows for constant monitoring of the operating mode and current welding parameters.
Technical specifications:
- MODEL MIG-250
- Power supply / phase (V-Ph) 230-1 +/- 15%
- Nominal input current 30 A
- Duty cycle 35%–250A, 60%–180A, 100%–160A
- Nominal power 4.8 kVA
- Output current range: 30-250A (30-100A wire used 0.6mm; 100-160A wire used 0.8mm; 160-250A wire used 1.0mm. Note - changing the diameter of the welding wire during operation will change the parameters on the control panel.
- MIG/MAG welding voltage range 15 – 26 V
- Maximum allowable spool weight 5 kg
- Gasless welding function yes
- No-load voltage, V 63
- MIG/MAG welding current range 30 – 250 A
- Welding wire diameter 0.8/ 0.9/ 1.0 mm
- Protection Built-in
- Protection class IP21
Complete set:
- Welding machine – 1 pc.
- MIG/MAG welding torch – 1 pc.
- Welding cable with electrode holder – 1 pc.
- Welding cable with ground clamp – 1 pc.
- User manual – 1 pc.
12 MONTHS WARRANTY AND AFTER-WARRANTY SERVICE
