Dahua outdoor CAT5 UTP Cable 1x305m PFM920-5EU (PFM9205EU)

Features:• 305m /carton outdoor UTP CAT5e, power over Ethernet, compatible with one cable.• High-purity (99.97%) Oxygen-Free Copper conductor material.• Customized MDPE outer sheath; meet ANSI/TIA 568-C.2 flame retardant class certified.• Environmentally friendly PVC and all materials used are RoHS compliant.Technical Specifications:• Material OFC (oxygen free copper) (99.97% purity).• Conductor diameter: 0.50 mm ± 0.01 mm.• American wire Gauge: 24AWG.• Insulation material: HDPE.• Insulation min. average thickness: 0.21mm.• Insulation diameter: 0.89mm±0.06mm.• Color: 8-core, blue, white/blue; orange, white/orange; green, white/green; brown, white/brown.• Sheath material: MDPE.• Sheath min. average thickness 0.7mm.• Sheath Diameter: 5.2 mm ± 0.4 mm.• Max. DC resistance of single conductor 9.5 Ohm/100m.• Min. insulation resistance 5000MOhm·km.• Max. DC resistance unbalance: 2% (pair intra), 4% (pairs inter).• Dielectric strength: No breakdown with 1KV DC for 1 min.• Max. attenuation: 22dB/100m@100MHz.• Characteristic impedance: 100 ± 15Ohm.• Near end cross talk: > /= 35.30 dB/100 m@100 MHz.• Return loss: > /= 20.1 dB/100 m@100 MHz.• Elongation at break: Sheath > /= 350%, Insulation > /= 300%.• Tensile strength: Sheath > /= 12 MPa, Insulation > /= 16 MPa.• Installation bending radius: > 8 times of outer cable diameter.• Conductor elongation at break: > /= 15%.• Shrinkage of insulation: < / = 5%.• Operation temperature: –30°C to +60°C.• Installation temperature: –5°C to +50°C.• Storage temperature: –10°C to +40°C; Humidity: <60%.• Length: 305m ± 1.5 m.• Packaging dimensions: 406mm × 404 mm × 216 mm.• Packaging method: 305m a carton, one protection carton with 2 cartons inside.• Net Weight: 8.5 (± 0.6) kg.• Packaging dimension 406mmx404mmx216mm.• Weight (with packaging): 9.3 (± 0.6) kg.• Executive standard: ANSI/TIA 568-C.2.
